Toku TNB10E Dust Grooved, Hard Rock Pyramid ToolToku TNB10E Dust Grooved, Hard Rock Pyramid Tool - 2Toku TNB10E Dust Grooved, Hard Rock Pyramid Tool - 3
Brand:TokuModel:TNB10EHKM code:238025938

Toku TNB10E Dust Grooved, Hard Rock Pyramid Tool

  • Breaker: Toku TNB10E
  • Tool type: Dust grooved, hard rock pyramid tool
  • Diameter: 115 mm
  • Length: 930 mm
  • Weight: 77 kg
  • Material: OEM quality, heat-treated alloy steel
  • Delivery: fast delivery from stock or made in 5 working days

Other breaker models using a Ø115 x 930 mm tool

Prices are visible to partners

Sign in to see partner pricing and order online.

We usually reply within 1 business day.

Ask on WhatsApp
How to order from abroad

Order online (partners)

  1. Apply as a partner.
  2. Once we approve your account, partner prices appear on the site.
  3. Add products to your cart and pay securely by credit card or bank transfer.
  4. Our sales team contacts you about the shipping method and cost.

Request a quote

  1. Send a quote request.
  2. We email the price (EXW Istanbul), stock and lead time, usually within 1 business day.
  3. On approval: proforma invoice and payment by bank transfer (USD or EUR).
  4. Shipping by weight: DHL Express, air freight or road/sea freight.

*Representative image. May vary depending on brand and model.

Dust grooved, hard rock pyramid tool for the Toku TNB10E hydraulic breaker: Ø115 mm diameter, 930 mm length, 77 kg. OEM quality, made from heat-treated alloy steel; fast delivery from stock or made in 5 working days.

Technical Data

Breaker Brand / ModelToku TNB10E
Tool TypePyramid Tool
OptionDust Grooved + Hard Rock
Diameter115 mm
Overall Length930 mm
Weight77 kg
MaterialHigh-nickel alloy steel, special hardening
Product Code238025938
DeliveryFast delivery from stock or made in 5 working days

Where Is a Pyramid Tool Used?

Pyramid tools penetrate non-abrasive materials of varying strength quickly. The pointed geometry and cutting angle give high penetration rates with little effort in concrete and similar materials.

  • Primary demolition
  • Secondary demolition
  • Trenching
  • Recycling
  • Tunneling
  • Primary breaking
  • Landscaping

According to the material table in our manual, it is recommended for massive (monolithic) sedimentary rock.

The dust grooves guide dust and fine particles away from the breaking zone. Visibility and precision improve, tool wear and heat build-up drop, and the tool keeps its performance longer.

The hard rock version is made from a high-nickel alloy and goes through a special hardening process. It withstands extreme impact forces and abrasive rock, and is the preferred choice for heavy quarrying and mining.

Correct Use: Three Rules

  • Work perpendicular. Keep the breaker at a right angle to the surface and avoid side loads. Angled pushing wears the bushings and moves the piston off the tool axis.
  • Do not pry. Rocking the tool like a lever before it is fully seated, or rotating the breaker while the tool is embedded, is the most common cause of tool breakage.
  • Do not blank fire. If the breaker strikes without the tool touching the surface, all the energy goes into the retaining pins and the tool's pin slots; pins break and slots are destroyed.

Breakage caused by ignoring these rules is not covered by the warranty. See our tool selection guide, the tool use section and the Tool User Manual and Warranty Terms.

Other Tool Types for Toku TNB10E

Tool Type and SizeOptions
Moil Point ToolØ115 x 930 mmStandard · Dust Grooved · Hard Rock · Dust Grooved + Hard Rock
Chisel ToolØ115 x 930 mmStandard · Dust Grooved · Hard Rock · Dust Grooved + Hard Rock
Pyramid ToolØ115 x 930 mmStandard · Dust Grooved · Hard Rock · Dust Grooved + Hard Rock (this page)
Blunt ToolØ115 x 930 mmStandard · Hard Rock

Wide chisel, tarmac cutter and driving tools are made to order; if you need one of these for your Toku TNB10E, write to sales@hkm.com.tr.

Manufacturing, Delivery and Warranty

HKM manufactures this tool to OEM quality from heat-treated alloy steel. Tools in stock ship quickly; if not in stock, the tool is made in 5 working days. Transport time is added depending on the method (road, air, sea).

Tools are warranted against manufacturing defects only; breakage caused by improper use is not covered.

Frequently Asked Questions

Q: What are the dimensions of the Toku TNB10E dust grooved, hard rock pyramid tool?

A: The Toku TNB10E dust grooved, hard rock pyramid tool is made for the Toku TNB10E hydraulic breaker: diameter 115 mm, overall length 930 mm, weight 77 kg. Just state your breaker brand and model when you order.

Q: Will another tool with the same diameter and length fit my Toku TNB10E?

A: Not always. The position and shape of the retaining pin slot change with brand and model; a tool with the same diameter and length may not fit. This tool is made to the slot dimensions of the Toku TNB10E.

Q: What is the Toku TNB10E dust grooved, hard rock pyramid tool used for?

A: The Toku TNB10E dust grooved, hard rock pyramid tool is mainly used for: primary demolition, secondary demolition, trenching, recycling, tunneling, primary breaking, landscaping. According to the material table in our manual, it is recommended for massive (monolithic) sedimentary rock.

Q: What do the dust grooves on the Toku TNB10E dust grooved, hard rock pyramid tool do?

A: The dust grooves guide dust and fine particles away from the breaking zone. Visibility and precision improve, tool wear and heat build-up drop, and the tool keeps its performance longer.

Q: When should I choose a hard rock pyramid tool for the Toku TNB10E?

A: The hard rock version is made from a high-nickel alloy and goes through a special hardening process. It withstands extreme impact forces and abrasive rock, and is the preferred choice for heavy quarrying and mining. For general demolition and construction the standard tool is enough.

Q: Which other tool types are available for the Toku TNB10E?

A: We make 14 different tools for the Toku TNB10E: moil point tools, chisel tools, pyramid tools, blunt tools, with dust grooved and hard rock options. You can reach all of them from the Other Tool Types table on this page.

Q: How long is the delivery time for the Toku TNB10E dust grooved, hard rock pyramid tool?

A: If the Toku TNB10E dust grooved, hard rock pyramid tool is in stock, it ships quickly. If not, it is made in 5 working days; transport time is added depending on the shipping method.

Q: Is the Toku TNB10E dust grooved, hard rock pyramid tool covered by warranty?

A: Like all HKM breaker tools, the Toku TNB10E dust grooved, hard rock pyramid tool is warranted against manufacturing defects only. The fracture surface is examined; if the fracture started from a flaw inside the material, the tool is covered. Breakage from prying, blank firing, rotating the embedded tool or working with worn bushings is not covered.

Q: What shortens the life of the Toku TNB10E dust grooved, hard rock pyramid tool the most?

A: Prying before the tool is fully seated, blank firing, striking one spot for too long, insufficient or wrong grease, and working with worn bushings.

Q: What else should I check when I change the tool on my Toku TNB10E?

A: Compare the inner diameters of the lower and upper bushings and the thrust bushing surface with the tolerances in your breaker's service manual. Worn bushings move the tool and piston off axis.

Q: What other names is the Toku TNB10E dust grooved, hard rock pyramid tool known by?

A: It is also called “pyramidal point”, “pyramidal moil point”, “pyramid moil”. Toku documents use “working tool”. Breaker tools in general are also known as breaker chisels, working tools or hammer tools.

Product Information

Weight (kg)
77
Dimensions
115x930x115 mm
Warranty
Please review the Tool User Manual and Warranty Terms document on this page. HKM breaker tools are warranted against manufacturing defects only. If a tool breaks, the fracture surface is examined; if the fracture started from a flaw inside the material, the tool is covered by the warranty. Damage caused by improper use is not covered: prying before the tool is fully seated, blank firing, rotating or side-loading the breaker while the tool is embedded, striking the surface with the tool using the boom, and working with worn bushings.
Delivery Information
Approx. 1 week
