Lifton LH110 Combined Bushing (Upper + Lower Bushing)

Aftermarket combined bushing in OEM quality for the Lifton LH110 hydraulic breaker (Ø80 x 155 mm). A combined bushing is a single piece that combines the upper bushing and the lower bushing in one body. It takes on the functions of both the upper bushing and the lower bushing: it centers the tool in the upper region, guides it at the front head outlet and absorbs lateral loads to reduce wear on the tool and body. Precision-machined from wear-resistant, heat-treated steel. Bushing dimensions can differ even within the same model depending on production year and housing type, so compare them with your existing bushing before ordering.

Specifications:
Consists of: Upper bushing + Lower bushing
Outer Diameter (max.): 80 mm
Length: 155 mm
Weight: 1.75 kg

Prices are visible to partners

Sign in to see partner pricing and order online.

We usually reply within 1 business day.

Ask on WhatsApp
How to order from abroad

Order online (partners)

  1. Apply as a partner.
  2. Once we approve your account, partner prices appear on the site.
  3. Add products to your cart and pay securely by credit card or bank transfer.
  4. Our sales team contacts you about the shipping method and cost.

Request a quote

  1. Send a quote request.
  2. We email the price (EXW Istanbul), stock and lead time, usually within 1 business day.
  3. On approval: proforma invoice and payment by bank transfer (USD or EUR).
  4. Shipping by weight: DHL Express, air freight or road/sea freight.

Lifton LH110 Hydraulic Breaker Combined Bushing (Upper + Lower Bushing)

The Lifton LH110 combined bushing is a single-piece bushing that combines the upper and lower bushing, and centers and guides the tool in both the upper and lower regions of the front head. It is manufactured as an aftermarket replacement part for Lifton LH110 hydraulic breakers. It is precision-machined from wear-resistant, heat-treated steel.

A combined bushing is a single piece that combines the upper bushing and the lower bushing in one body.

TECHNICAL SPECIFICATIONS

Compatible BrandLifton
Compatible ModelLH110
Part TypeCombined bushing
Consists ofUpper bushing + Lower bushing
Outer Diameter (max.)80 mm
Length155 mm
Weight1.75 kg
MaterialWear-resistant, heat-treated steel

Before ordering, compare the dimensions of your existing part with these values.

Important: design differences by model and production year

Bushing designs vary by brand and model, and even by the production year of the same model and by whether the breaker is a silenced (box type) or tunnel type unit. Two breakers with the same model name can use bushings of different size and shape.

If you send the technical drawing of your part to sales@hkm.com.tr, we can manufacture it to your drawing.

WHICH BUSHINGS DOES THIS PART INCLUDE?

  • Upper bushing
  • Lower bushing

FEATURES

  • Single-piece design: upper and lower bushing in one body
  • Wear-resistant, heat-treated steel
  • Precise bore tolerance
  • Made to OEM dimensions
  • Produced with bore, concentricity and hardness control

WHAT DOES A COMBINED BUSHING DO?

It takes on the functions of both the upper bushing and the lower bushing: it centers the tool in the upper region, guides it at the front head outlet and absorbs lateral loads to reduce wear on the tool and body.

Other names used for this part include combine bushing.

INSTALLATION AND MAINTENANCE NOTES

  • Check the tool's lateral play regularly; increasing play is the first sign of bushing wear.
  • If the play exceeds the wear limit in your manual, replace the bushing and the seal kit together; replacing only the seal is a temporary fix.

Detailed guide: Bushing wear: why seal replacement alone fails

WHAT IS INCLUDED?

Quantity: 1 combined bushing (upper and lower bushing in one piece). If you also need a seal kit, contact our sales team.


Frequently Asked Questions

Q: Does this combined bushing fit my Lifton LH110 breaker?
A: It is manufactured for the Lifton LH110. The same model may have been built with different designs in different production years or housing types, so please compare the outer diameter and length with your existing bushing, or send us the OEM part number before ordering.

Q: Which bushings does a combined bushing consist of?
A: A combined bushing is a single piece that combines the upper bushing and the lower bushing in one body, so you do not need to order these two bushings separately. Compare the dimensions with your existing part.

Q: When should the combined bushing be replaced?
A: When the tool's lateral play exceeds the wear limit in your breaker's manual. If the breaker leaks oil at the tool end, measure the play first: above the limit, replace the bushing and the seal kit together; below the limit, replacing only the seal kit is enough. The limit depends on the model, so check your manual or send us the model code.

Q: What other names are used for the combined bushing?
A: Other names used for this part include combine bushing.

Q: What if the part in my breaker does not match these dimensions?
A: Send the dimensions or the technical drawing of your current part to sales@hkm.com.tr. We will identify the right part with you and, if needed, manufacture it to your drawing.

Q: Is shipping included in the price?
A: No, shipping is not included in our prices. Please contact our sales team for the best delivery option to your location.

Not sure which bushing fits?

Send us your breaker's brand and model, the OEM part number if you have it, the dimensions of your current part or its technical drawing, and we will prepare the matching part and a quote. We can manufacture to your drawing. We ship spare parts to more than 70 countries.

Email our sales team: sales@hkm.com.tr

Lifton and the model names shown are trademarks of their respective owners and are used only to indicate compatibility.

Product Information

Weight (kg)
1.75
Dimensions
80x80x155 mm
Warranty
Bushings are consumable wear parts subject to natural degradation due to continuous contact and friction with the tool during operation. Consequently, wear resulting from normal use, galling/scoring caused by insufficient periodic lubrication (greasing), and breakages resulting from improper prying (lateral force) applied to the tool during breaking operations are not covered by the warranty. Bushings are solely guaranteed against manufacturing and heat treatment defects that are identified prior to or immediately upon initial use.
Delivery Information
Approx. 1 week
