HKM AG120 Drive Unit, Hydraulic Auger

HKM AG120 – Drive Unit

Heavy-Duty Powerhouse for Demanding Applications

The HKM AG120 Drive Unit is engineered for 13–17 ton class excavators, delivering 12,000 Nm of torque and operating smoothly between 22–48 RPM. Designed for high-flow hydraulic systems, it ensures stability and power across deep and tough ground layers.

Its high-strength planetary gearbox offers long-lasting performance, while the 75 mm square shaft guarantees full compatibility with large-diameter augers. AG120 is the professional choice for infrastructure, agriculture, and construction works.

Key Specifications:

• Torque: 12,000 Nm
• Speed: 22–48 RPM
• Oil Flow: 70–150 L/min
• Operating Pressure: 80–240 bar
• Output Shaft: 75 mm square

Why Choose AG120:

• Ideal for 13–17 ton excavators
• High torque with stable performance in heavy workloads
• Rugged planetary gearbox design
• Reliable torque delivery via square shaft
• Best fit for foundation, utility, and deep soil drilling
