HKM RP20 Ripper

HKM RP20 Ripper is a compact tool for 18–26 ton carriers. With 426 kg weight and 1300 mm height, it delivers efficient ripping in frozen or compacted ground.

HKM Ripper Catalogue_2025.pdf (4.32 MB)

HKM Riper Katalog_2025.pdf (4.33 MB)

Prices are visible to partners

Partner Login Request a Quote

HKM RP25 Ripper is a mid-range solution tailored for 26–35 ton excavators, combining a 575 kg operating weight with 1415 mm height for superior leverage and penetration. Engineered with wear-resistant steel and a replaceable D85C tooth, RP25 effortlessly rips through compacted soils, frozen layers, and fractured rock. The 520 mm pin-to-pin spacing ensures seamless integration with a wide range of machines.

Benefits

Increased Productivity: Fast fracture and remove obstacles with minimal passes
Reduced Operating Costs: Lower labor and fuel consumption
Extended Service Life: Premium material quality and modular design to maximize its durability
Simplified Maintenance: Sealed pin shaft and replaceable wear parts minimize upkeep

Application Areas (Suitable For)

Compacted & Hardened Soils: Stiff, high-density earth layers that resist standard digging
Frozen Ground & Permafrost: Sub-zero, ice-bonded soil conditions
Soft Rock Seams & Weathered Stone: Fractured or friable rock zones
Loose Geological Materials: Sandy, silty or mixed fill in trenching and site-prep operations

Key Features

High-Grade Manganese Steel body for extreme wear resistance
Alloy Pin Shaft with built-in lubrication passages for superior toughness
Interchangeable Bolt-On Teeth for fast, tool-free replacement
Durable Mounting Bracket engineered to withstand high bending forces

TECHNICAL SPECIFICATIONS

Carrier Weight (ton)	26–35
Operating Weight (kg)	575
Pin to Pin Distance A (mm)	520
Width B (mm)	950
Height C (mm)	1415
Plate Thickness (mm)	80
Teeth Model (type)	D85C
