HKM RP35 Ripper

HKM RP35 Ripper is built for 40–50 ton excavators. Weighing 850 kg with 1665 mm height, it handles demanding ripping jobs with high efficiency.

HKM Ripper Catalogue_2025.pdf (4.32 MB)

HKM Riper Katalog_2025.pdf (4.33 MB)

Prices are visible to partners

Partner Login Request a Quote

HKM RP35 Ripper is a powerful attachment built for 40–50 ton excavators. With an operating weight of 850 kg and a towering height of 1665 mm, it delivers exceptional ripping force through reinforced terrain. The standard 4T5502 bolt-on tooth ensures fast, aggressive penetration, while the 570 mm pin spacing guarantees compatibility with large earthmoving machines.

Benefits

Increased Productivity: Fast fracture and remove obstacles with minimal passes
Reduced Operating Costs: Lower labor and fuel consumption
Extended Service Life: Premium material quality and modular design to maximize its durability
Simplified Maintenance: Sealed pin shaft and replaceable wear parts minimize upkeep

Application Areas (Suitable For)

Compacted & Hardened Soils: Stiff, high-density earth layers that resist standard digging
Frozen Ground & Permafrost: Sub-zero, ice-bonded soil conditions
Soft Rock Seams & Weathered Stone: Fractured or friable rock zones
Loose Geological Materials: Sandy, silty or mixed fill in trenching and site-prep operations

Key Features

High-Grade Manganese Steel body for extreme wear resistance
Alloy Pin Shaft with built-in lubrication passages for superior toughness
Interchangeable Bolt-On Teeth for fast, tool-free replacement
Durable Mounting Bracket engineered to withstand high bending forces

TECHNICAL SPECIFICATIONS

Carrier Weight (ton)	40–50
Operating Weight (kg)	850
Pin to Pin Distance A (mm)	570
Width B (mm)	1166
Height C (mm)	1665
Plate Thickness (mm)	90
Teeth Model (type)	4T5502
