HKM RP20
Ripper
HKM RP20 Ripper is a compact tool for 18–26 ton carriers. With 426 kg weight and 1300 mm height, it delivers efficient ripping in frozen or compacted ground.
Campaign
HKM RP25 Ripper is a mid-range solution tailored for 26–35 ton excavators, combining a 575 kg operating weight with 1415 mm height for superior leverage and penetration. Engineered with wear-resistant steel and a replaceable D85C tooth, RP25 effortlessly rips through compacted soils, frozen layers, and fractured rock. The 520 mm pin-to-pin spacing ensures seamless integration with a wide range of machines.
Benefits
- Increased Productivity: Fast fracture and remove obstacles with minimal passes
- Reduced Operating Costs: Lower labor and fuel consumption
- Extended Service Life: Premium material quality and modular design to maximize its durability
- Simplified Maintenance: Sealed pin shaft and replaceable wear parts minimize upkeep
Application Areas (Suitable For)
- Compacted & Hardened Soils: Stiff, high-density earth layers that resist standard digging
- Frozen Ground & Permafrost: Sub-zero, ice-bonded soil conditions
- Soft Rock Seams & Weathered Stone: Fractured or friable rock zones
- Loose Geological Materials: Sandy, silty or mixed fill in trenching and site-prep operations
Key Features
- High-Grade Manganese Steel body for extreme wear resistance
- Alloy Pin Shaft with built-in lubrication passages for superior toughness
- Interchangeable Bolt-On Teeth for fast, tool-free replacement
- Durable Mounting Bracket engineered to withstand high bending forces
TECHNICAL SPECIFICATIONS
| Carrier Weight (ton) | 26–35 |
| Operating Weight (kg) | 575 |
| Pin to Pin Distance A (mm) | 520 |
| Width B (mm) | 950 |
| Height C (mm) | 1415 |
| Plate Thickness (mm) | 80 |
| Teeth Model (type) | D85C |
