HKM RP40
Ripper
HKM RP40 Ripper is designed for 50–65 ton carriers. With 1320 kg operating weight and 1788 mm height, it delivers powerful results in harsh conditions.
Campaign
HKM RP40 Ripper is engineered for 50–65 ton excavators, combining brute strength with structural resilience. Weighing in at 1320 kg with a height of 1788 mm, this heavy-duty ripper is built to penetrate compacted terrain with maximum efficiency. Its 600 mm pin spacing and D11 tooth model ensure compatibility with large-scale machinery and reliable cutting performance in extreme environments.
Benefits
- Increased Productivity: Fast fracture and remove obstacles with minimal passes
- Reduced Operating Costs: Lower labor and fuel consumption
- Extended Service Life: Premium material quality and modular design to maximize its durability
- Simplified Maintenance: Sealed pin shaft and replaceable wear parts minimize upkeep
Application Areas (Suitable For)
- Compacted & Hardened Soils: Stiff, high-density earth layers that resist standard digging
- Frozen Ground & Permafrost: Sub-zero, ice-bonded soil conditions
- Soft Rock Seams & Weathered Stone: Fractured or friable rock zones
- Loose Geological Materials: Sandy, silty or mixed fill in trenching and site-prep operations
Key Features
- High-Grade Manganese Steel body for extreme wear resistance
- Alloy Pin Shaft with built-in lubrication passages for superior toughness
- Interchangeable Bolt-On Teeth for fast, tool-free replacement
- Durable Mounting Bracket engineered to withstand high bending forces
TECHNICAL SPECIFICATIONS
| Carrier Weight (ton) | 50–65 |
| Operating Weight (kg) | 1320 |
| Pin to Pin Distance A (mm) | 600 |
| Width B (mm) | 1227 |
| Height C (mm) | 1788 |
| Plate Thickness (mm) | 100 |
| Teeth Model (type) | D11 |
