Ripper

HKM RP30 Ripper is designed for excavators in the 30–40 ton class, offering a 730 kg operating weight and a robust 1495 mm body height for powerful ground penetration. Fitted with the durable 4T5502 tooth and a reinforced manganese steel frame, RP30 rips through compacted, frozen, or fractured terrain with ease. Its 570 mm pin-to-pin distance ensures optimal fitment across a wide range of heavy equipment.

Benefits

• Increased Productivity: Fast fracture and remove obstacles with minimal passes
• Reduced Operating Costs: Lower labor and fuel consumption
• Extended Service Life: Premium material quality and modular design to maximize its durability
• Simplified Maintenance: Sealed pin shaft and replaceable wear parts minimize upkeep

Application Areas (Suitable For)

• Compacted & Hardened Soils: Stiff, high-density earth layers that resist standard digging
• Frozen Ground & Permafrost: Sub-zero, ice-bonded soil conditions
• Soft Rock Seams & Weathered Stone: Fractured or friable rock zones
• Loose Geological Materials: Sandy, silty or mixed fill in trenching and site-prep operations

Key Features

• High-Grade Manganese Steel body for extreme wear resistance
• Alloy Pin Shaft with built-in lubrication passages for superior toughness
• Interchangeable Bolt-On Teeth for fast, tool-free replacement
• Durable Mounting Bracket engineered to withstand high bending forces

TECHNICAL SPECIFICATIONS
