HKM RP40 Ripper

HKM RP40 Ripper is designed for 50–65 ton carriers. With 1320 kg operating weight and 1788 mm height, it delivers powerful results in harsh conditions.

HKM Ripper Catalogue_2025.pdf (4.32 MB)

HKM Riper Katalog_2025.pdf (4.33 MB)

Prices are visible to partners

Partner Login Request a Quote

HKM RP40 Ripper is engineered for 50–65 ton excavators, combining brute strength with structural resilience. Weighing in at 1320 kg with a height of 1788 mm, this heavy-duty ripper is built to penetrate compacted terrain with maximum efficiency. Its 600 mm pin spacing and D11 tooth model ensure compatibility with large-scale machinery and reliable cutting performance in extreme environments.

Benefits

Increased Productivity: Fast fracture and remove obstacles with minimal passes
Reduced Operating Costs: Lower labor and fuel consumption
Extended Service Life: Premium material quality and modular design to maximize its durability
Simplified Maintenance: Sealed pin shaft and replaceable wear parts minimize upkeep

Application Areas (Suitable For)

Compacted & Hardened Soils: Stiff, high-density earth layers that resist standard digging
Frozen Ground & Permafrost: Sub-zero, ice-bonded soil conditions
Soft Rock Seams & Weathered Stone: Fractured or friable rock zones
Loose Geological Materials: Sandy, silty or mixed fill in trenching and site-prep operations

Key Features

High-Grade Manganese Steel body for extreme wear resistance
Alloy Pin Shaft with built-in lubrication passages for superior toughness
Interchangeable Bolt-On Teeth for fast, tool-free replacement
Durable Mounting Bracket engineered to withstand high bending forces

TECHNICAL SPECIFICATIONS

Carrier Weight (ton)	50–65
Operating Weight (kg)	1320
Pin to Pin Distance A (mm)	600
Width B (mm)	1227
Height C (mm)	1788
Plate Thickness (mm)	100
Teeth Model (type)	D11
