HKM RS100 Hydraulic Breaker

HKM RS100 Hydraulic Breaker

HKM RED LINE - RS100: THE COMPACT BREAKER THAT WORKS UNDERGROUND

HKM Red Line RS100 is engineered for maximum efficiency, durability, and reliable performance in urban construction, light demolition, and foundation works.
Fully compatible with 10-16 ton excavators, this model combines a high-pressure accumulator, dust-protected structure, and a fully hydraulic system to meet the challenges of tough jobsite conditions with ease.

RS100: DUST STAYS OUT, WORK GOES ON

With an operating pressure of 120-140 bar and oil flow of 70-100 l/min, the RS100 delivers stable performance without overloading the carrier.
Its 960 kg operating weight and 100 mm tool diameter provide solid impact force for small to mid-scale operations.

Thanks to its simplified tie rod design, RS100 offers significantly reduced maintenance needs compared to conventional models - minimizing downtime and lowering operating costs.
The optional single-piece bushing design ensures better wear resistance during vertical applications such as tunnel projects.
Wear-resistant parts and optional dust-proof kits make the RS100 a dependable breaker in a variety of demanding environments.

RS100 is a smart investment for professionals who need long service life, minimal maintenance, and strong breaking power in a compact package.

KEY FEATURES

• Full hydraulic system for reliable and durable operation
• High-pressure accumulator for consistent impact energy
• Simplified internal design for reduced maintenance costs
• Optional single-piece bushing ideal for vertical/tunnel use
• Dust protection and wear-resistant components for harsh conditions

INCLUDED IN THE SET

• Hydraulic Breaker Machine
• Mounting Bracket
• Breaker Tools (1 pcs Chisel Tool, 1 pcs Moil Point Tool)
• Hydraulic Connection Hoses
• Carrier Connection Pins
• Tool Box

STANDARD EQUIPMENTS

• High-Pressure Accumulator
• High Efficiency & Performance
• Dust Protection
• Solid Housing Design
• Vibration Absorption
• Noise Absorption

OPTIONAL EQUIPMENTS

• Automatic Lubrication System
• Underwater Kit
• Reinforced Outer Housing
• Fast Attachment Replacement Device

TECHNICAL SPECIFICATIONS

Frequently Asked Questions (FAQ)

Q: What size excavator is the HKM RS100 compatible with?
A: The RS100 is designed for excavators ranging from 10 to 16 tons. It provides optimal balance and performance for this specific weight class.

Q: Is this breaker suitable for tunnel or vertical applications?
A: Yes, the RS100 features dust protection and an optional single-piece bushing design, making it highly durable for vertical and dusty applications like tunneling.

Q: What is the tool diameter for the RS100?
A: The RS100 uses a 100mm diameter tool (chisel/moil point), which provides powerful breaking force for general construction and demolition tasks.

Q: Does the RS100 replace the R100?
A: It is the same breaker with a new code. R100 became RS100, while the 960 kg operating weight, 100 mm tool diameter, dust-protected bushing and 10-16 ton carrier range stayed exactly as they were. All R100 spare parts and chisels remain compatible.
